| Number |
Name |
Quantity |
| 1 |
Manifold block (3) |
1 |
| 2 |
Double-acting cylinder (4) |
2 |
| 3 |
Single-acting cylinder (5) |
1 |
| 4 |
5/3 solenoid directional control valve (center closed type) (6) |
1 |
| 5 |
5/3 solenoid directional control valve (center exhaust type) (7) |
1 |
| 6 |
5/3 solenoid directional control valve (center pressure type) (8) |
1 |
| 7 |
5/2 single solenoid control shuttle valve (9) |
2 |
| 8 |
5/2 double solenoid control directional control valve (10) |
2 |
| 9 |
3/2 single solenoid control shuttle valve (NC) (11) |
1 |
| 10 |
3/2 single solenoid control shuttle valve (NO) (12) |
1 |
| 11 |
Manual valve (spring return) (13) |
1 |
| 12 |
5/2 handle shuttle valve (14) |
1 |
| 13 |
5/3 handle shuttle valve (15) |
1 |
| 14 |
Single pneumatically controlled 2/3-way valve (16) |
1 |
| 15 |
Double pneumatically controlled 2/3-way valve (17) |
1 |
| 16 |
Single air-controlled 2/5-way valve (18) |
1 |
| 17 |
Double air-controlled 2/5-way valve (19) |
2 |
| 18 |
Two-way pressure reducing valve (20) |
1 |
| 19 |
Pressure reducing valve (21) |
2 |
| 20 |
Check valve (22) |
2 |
| 21 |
Pressure gauge (23) |
2 |
| 22 |
One-way throttle valve (24) |
2 |
| 23 |
3/2-way knob valve (25) |
1 |
| 24 |
3/2-way valve (roller lever) (26) |
2 |
| 25 |
3/2-way valve (roller lever) (27) |
2 |
| 26 |
3/2-way pushbutton valve (28) |
1 |
| 27 |
Time delay valve (29) |
1 |
| 28 |
Sequence valve (30) |
1 |
| 29 |
"AND" type dual pressure valve (31) |
2 |
| 30 |
"OR" type shuttle valve (32) |
2 |
| 31 |
Quick exhaust valve (33) |
1 |
| 32 |
Micro switch (left) (34) |
2 |
| 33 |
Micro switch (right) (35) |
2 |
| 34 |
Photoelectric sensor (36) |
1 |
| 35 |
Capacitive sensor (37) |
1 |
| 36 |
Inductive sensor (38) |
1 |
